Features
1:5xCree XHP35 High Intensity LED with a lifespan of 50,000hours
2:Max Output 12,000 lumens
3:Powered by 4x18650 3100mAh rechargeable battery
4:Approximate runtimes in each brightness level:
Ultra-Low: 2 lumens; 225 hours; 14 meters; 51cd
Low: 500 lumens; 12 hours; 253 meters; 16000cd
Mid 1: 1500 lumens; 4 hours; 403 meters; 40600cd
Mid 2: 3500 lumens; 1.7 hours; 608 meters; 92400cd
High: 6000 - 4200 lumens; 7 minutes + 55 minutes; 1064 meters; 283200cd
Turbo: 12000 - 4200 lumens; 1.5 minutes + 50 minutes; 1403 meters; 492000cd
Strobe: 3500 lumens; 3.5 hours
5:Max runtime 225 hours
6:Max beam distance 1403 meters
7:Peak beam intensity 492000cd
8:Working Voltage:12V-16.8V
9:Impact resistant: 1 meter
10:Waterproofing: IPX8 standard to 5 meters submersible
11:Size: 186.6mm (length) x 108mm (head diameter) x 53mm (tube diameter)
12:Weight: 587.75g without batteries; battery carrier 61.75g
13:6 brightness levels and special Strobe function available
14:Stainless steel side switch for fast and convenient operation
15:Built-in intelligent temperature controller is used and adjusted brightness according to work status and temperature
16:All circuitry contact points are gold-plated, providing better conductivity and superior durability
17:Tail stand; The standard tripod socket compatibility; Lock-out function
18:Reverse polarity protection, to protect from improper battery insertion
19:Power indicator displays battery voltage,Low-voltage warning reminds when battery charging is needed
20:Toughened ultra-clear glass lens with anti-reflective coating
21:Made of durable aerospace-grade aluminum alloy
22:Premium type Ⅲ hard-anodized anti-abrasive finish
23:IPX8 waterproof (5 meters submersible)
24:Impact resistance to 1 meter
Warning
1. The light must be powered by 4 x ACEBEAM ARC18650H-310A battery with 10Amps of current or the major brand batteries with the same Voltage, Capacity and Watt hour ratings as original. The light may not be turned on when using other brand battery with the less current.
2.Do not mix and match brands and models, old and new, used and unused batteries. Recommend using ACEBEAM branded batteries or major manufacturers’ batteries with
the same Voltage, Capacity and Watt hour ratings as original.
3.Unauthorized disassembly may damage the flashlight and void the warranty.
4.It is normal if the surface heat is increased during use due to the excellent thermal conductivity technology. It is suggested to turn down lower mode of brightness or turn off
the light to cool down. It is suggested to use in a well ventilated area with ambient temperature.
5.Caution hot when using continuously for a long time. Do not put it on flammable materials for a long time, any fire or any safety problems caused by this will not be related to
the manufacturer and distributors.
6.Please check and replace the O-ring regularly to maintain the waterproof rating.
7.Please check and lubricate the threads regularly with professional lubricant.
8.Clean the contact surfaces regularly to keep the flashlight normal operation. If irregular strobe or failure to turn-on occurs, the contact surfaces may be dirty and requires cleaning by using alcohol cotton swabs.
9.Remove the battery from the flashlight during long term storage.
10.This flashlight is not intended to be used as a diving light.
11.Do not aim the flashlight directly at eyes. Users must be over 18 years of age. Keep out of the reach of children.
Existing reviews
Acebeam X65 mini Review
Delivery package:
Nice looking package with all basic instructions outside. The flashlight has a good protection during the transport.
Points/Maximal points: 4,5/5
Included accessories:
Complete, including 4 18650 3100 mAh protected Acebeam batteries.
Points/Maximal points: 9,5/10
User manual:
The user manual Includes all basic information, but I should appreciate a larger text font.
Points/Maximal points: 4,5/5
Available functions:
All basic functions inclusive direct access to low mode is there. There is also a battery indicator in place witch continuously lights with different colors:
Green (plus 12.6 V)
Constant red (11.6 to 12.6 V)
Flashing red (below 11.6 V)
I should have liked a built in charging possibility with a USBC charging function on the light, and also a possibility to use the flashlight as a power bank.
Points/Maximal points: 8,5/10
Light performance:
Very bright, 12 000 Lumens/492 000 candela. I measured 499 500 candelas with my own candela measurement. So, it seems to be a realistic indication of candela from Acebeam. That gives a calculated distance throw for a little more than 1 400 m.
X65 mini also shows a good combination between flood and throw. Impressing!
Points/Maximal points: 9,5/10
Light "quality":
A combination of flood and throw, much of all. Color temperature 6500K. (I personally like this level of color temperature)
Well defined large center spot with a typical five LED light parable look.
Points/Maximal points: 9,5/10
Runtime:
A little more runtime should be possible if the battery size 21700 were used instead of 18650. Of course the flashlight should be somewhat larger and heavier…
Points/Maximal points: 9,5/10
Ease to use:
The different flashlight functions are easy to use and understand.
Extra plus for the excellent metallic, electronic maneuver button, it feels precise, exact and are relatively easy to find also in the dark. The lanyard attachment ring is screwed into the tripod screw hole. A verry robust and god solution.
Points/Maximal points: 10/10
Form factor:
Probably hard to make a flashlight with this kind of performance much smaller and lighter. You need a certain amount mass to take away the heat generated from the five high performance leds….
Points/Maximal points: 10/10
Build quality/finish:
Very nice looks and finish. Perfectly centered leds. A great quality feeling in this flashlight!
Points/Maximal points: 10/10
Value for money:
Not cheap, but robust built and includes battery and everything you need. Probably a state-of-the-art flashlight for the rescue worker or the flashlight enthusiasts who like a very high-performance flashlight with both very long range and a lot of flood light.
Points/Maximal points: 9/10
Total points: 95/100 This is definitely a “Five Star” product!
And finally, the most important questions:
Want to have/buy again?
Yes, and yes. definitely, this is a reference light for me!
